T60 Hydroseeder

Finn Machines

Hyrdroseeders

Finn invented and trademarked the first Hydroseeder® in 1953. Designed to mix and spray a slurry of seed and fertilizer over broad areas, this was more than a product innovation — it was the seed that spawned a new industry of turf and erosion control contractors.

May also be available in our Pre-Owned section, please click here

Specification

POWER	Kohler CH730, 23.5 hp (17.5 kw), 2 cylinder, OHV, air cooled gas
ENGINE SAFETY SYSTEM	Low oil pressure shutoff
TANK SIZE	600 gallon (2,270 liter) liquid capacity 500 gallon (1,890 liter) working capacity
LOADS PER ACRE*	6
FUEL TANK CAPACITY	8.2 gallon (31 liter)
PUMP	Centrifugal 3” x 1 1/2” (7.5 cm x 3.75 cm), 65 GPM @ 75 psi (245 lpm @ 5.3 kg/cm2), 3/4” (1.9 cm) solid clearance, adjustable
PUMP DRIVE	Direct drive through electric clutch, pump drive is independent of agitator operation
AGITATION	Mechanical paddle agitation and liquid recirculation
AGITATOR DRIVE	Reversible, variable speed hydraulic motor (0-110 rpm), with control lever at front and rear of unit
DISCHARGE DISTANCE	Up to 90 ft. (27 m) from end of discharge tower
MAX. MATERIAL	1,550 lbs. (703 kg) granular solids,
CAPACITY	200 – 250 lbs. (91 – 113 kg) fiber mulch
NOZZLES	(1) narrow fan, (1) wide fan, (1) long distance
EMPTY WEIGHT	T60T 2,770 lbs. (1,257 kg) T60S 2,170 lbs. (985 kg)
WORKING WEIGHT*	T60T 7,770 lbs. (3,525 kg) T60S 7,170 lbs. (3,253 kg)
TRAILER	Mounting on a UK type approved trailer is an option

*Loads per acre based on an application rate of 1500 lbs. mulch/acre.
*Working weights are approximate and do not include stored materials.

*Tower is optional.
Models shown may include optional equipment.

Description

The FINN T60 Series II is the ideal 600 gallon HydroSeeder for the landscaper or contractor that requires a fast and economical solution for seeding jobs. FINN developed HydroSeeder technology in 1953. We’ve been the industry leader in quality and innovation ever since. With the FINN T60, you don’t have to settle for less than proven and reliable FINN quality to tackle a wide range of demanding hydroseeding applications.

Highly Efficient. Widely Applied

Become a one-man seeding and mulching crew. The T60 Series II covers up to 7,200 square feet per load with seed, fertilizer, and mulch in a simple, one-step process. Residential and commercial properties, sports fields, apartments, condominiums, and golf courses are all ideal ground for a T60 Series II application.

Top Design & Performance

TThe FINN T60 Series II HydroSeeder features a clean, operator-friendly design. For optimum mixing efficiency the T60 Series II features hydraulically controlled paddle agitation with convenient operator controls at both the front and rear of the unit. A low machine profile allows for easy material loading and excellent stability.

Powerfully Driven

The T60 Series II boasts a powerful centrifugal slurry pump, driven by an in-line common shaft clutch with no high-cost maintenance couplings, drive belts or hydraulic components. This configuration dramatically increases output and operating pressure.

As the world leader for over 80 years in the design and manufacture of innovative, quality equipment for the green industry, and as the inventor of the HydroSeeder, FINN Corporation is committed to your complete satisfaction.

FINN Corporation has a policy of continuous product improvement, and reserves the right to change design and specifications without notice. HydroSeeder® and the FINN Design® Logo are registered trademarks of FINN Corporation.
